RAMALLO

Xstorage  berth:



Located at about Km329.43 on the west side of the Paraná River. Berth coordinates are 33° 27.5’S, 60° 01.6’W. General layout of the Jetty installation enclosed. The BA Chart for this area is BA 1982A. The local chart covering this area is Chart No. H-1016. The average current speed at the Jetty location is about 2 knots and is influenced by the prevailing meteorological conditions (wind and rainfall within nearby and distant locations.) The River is basically non tidal at this location, is fresh water, and the water flow direction down river.



                 GAS OIL TANKS CAPACITY: 82000 M3

                 GAS OIL TANKS CAPACITY: 20000 M3

          LOADING/DISCHARGING RATE

                                              GAS OIL: 1200M3/HR

                                               NAPTHA: 450 M3/HR



Maximum vessel Displacement: 65,000 MT Max.

Min. LOA : 230m / 40 m (*)

Max Draft Alongside: 10.40 m FW (**)

Min. UKC Alongside: 0.50 m

 (*) 40 m = Minimum parallel body length.

 (**) May vary & Max. draft to be advised by local agents



No daylight restriction for berthing or unberthing operations at XSTORAGE’s jetty for vessels less than 190 m LOA,

Vessels greater than 190 m LOA are restricted to daylight berthing only. During unberthing operations, vessels are not to swing off the berth and should initially proceed up river before turning down river.
